850 pound lift and articulate capacity permits use with any size patient while eliminating frantic concerns for patient safety with obese patients.
Top rotation of 180 degrees maintains correct patient orientation with respect to the controls of the table while, at the same time, it places the base of the table out of the way.
One touch pendant control provides simple operation from any point around the entire perimeter of the table. Clearly labeled function buttons simplify use and enhance patient safety. Built-in safety provision assures that the brakes will be locked before functioning the table.
Narrow base design provides ample toe space clearance for the surgical staff and en easy to clean, aesthetically attractive stainless steel cover.
Built-in kidney bridge is designed with a "free floating" radiolucent patient support to reduce the risk of pressure points and post-operative trauma.
Full width quick-release bar on manually operated head section is easy to locate in an emergency.
PHYSICAL SPECIFICATIONS
- Weight Capacity: 850 lbs.
- Height Adjustment : 27” to 44”
- Top Rotation: 180°
- Foot / Leg Down: 105° (Removable)
- Foot / Leg Up: 20°
- Back Down: 40°
- Back Up: 60°
- Trendelenburg and Reverse Trendelenburg: 20°
- Lateral Tilt: 20°
ELECTRICAL SPECIFICATIONS
- Power Requirements: 120 VAC, 60 HZ 300 Watts
- Current Leakage: Less than 100 Microamps
- Power Cord: 15 Feet with Standard Duplex Connector
